DJI Zenmuse V1 Speaker for Matrice 350/Matrice 300

Specifications

• Product Name: Zenmuse V1
• Weight: 690±10 g
• Dimensions: 134×119×140 mm (L×W×H)
• Rated Power: 30 W
• Supported Aircraft: Matrice 300 RTK (requires DJI RC Plus), Matrice 350 RTK
• Shell Temperature: <50° C (122° F, plastic shell)
• Ingress Protection Rating: IP54
• Operating Temperature: -20° to 50° C (-4° to 122° F)
• Storage Temperature: -20° to 60° C (-4° to 140° F)
• Stabilization System: Single-axis (tilt)
• Angular Vibration Range: Hover: ±0.01°, Flight: ±0.02°
• Mounting: Detachable DJI SKYPORT
• Mechanical Range: Tilt: -125° to +25°
• Controllable Range: Tilt: -120° to +20°
• Operation Mode: Follow / Free / Re-center
• Impedance: 4 Ω
• Nominal Power: 25 W
• Effective Broadcast Distance: 500 m
• Max Sound Pressure Level: 127 dB @1 m
• Effective Bandwidth: 800 Hz to 8 kHz
• Record & Broadcast: Record & broadcast, local playback, and storage
• Text-to-Speech: Text-to-speech and storage (supports English and Mandarin Chinese)
• Audio File Playback: Supports importing local files in MP3, AAC, and WAV formats
• Playback Control: Start / Stop recording / Loop playback / Volume adjustment
• Remote Controller Button: Can set one button to press once to start recording, and press again to stop and play the recording
• Gimbal Synchronization: Supports synchronized control with other gimbal-equipped payloads
• Directional Audio Recording: The remote controller supports directional audio pickup and environmental noise reduction
• Payload Protection: Speaker temperature protection, overcurrent protection, and power protection to prevent damage
